MAXDATA PLATINUM Server Board User’s Manual
23
Server Board Bumpers
If you are installing your server board in a non-Intel
®
chassis, you must provide and install
rubber bumpers at the locations shown below. They must be the same height as the existing
board mount standoffs.
CAUTION
You must install rubber bumpers in all non Intel
®
chassis that do not already support the
board at the locations shown in the illustration.
The rubber bumpers you provide and install must be the same height as the existing board
mount standoffs to properly support your new board.
Failure to install bumpers, or installing bumpers that are too tall or too short, may damage
your board.
DO NOT INSTALL server board bumpers in the Intel SR1200 and SR2200 server chassis.
Figure 7. Installing Server Board Bumpers
