MAXDATA PLATINUM Server Board User’s Manual
46
Onboard Video Submenu
Feature Choices Description
Onboard Video Enabled Enables the embedded video controller.
Disabled
Peripheral Configuration Submenu
Feature Choices Description
Serial Port 1 Address Disabled Used to configure the serial port address.
3F8 If console redirection is used, verify that the I/O and
2F8 IRQ are identical to values configured in the “Server
3E8 Setup” menu.
2E8
Serial Port 1 IRQ 4 Used to configure the interrupt for serial port 1.
3
Serial Port 2 Address Disabled Used to configure the serial port address.
3F8 If console redirection is used, verify that the I/O and
2F8 IRQ are identical to values configured in the “Server
3E8 Setup” menu.
2E8
Serial Port 2 IRQ 4 Used to configure the interrupt for serial port 2.
3
Diskette Controller Enabled Used to enable or disable the onboard floppy disk
Disabled controller.
Legacy USB Support Disabled Enables support for legacy USB.
Keyboard Only
Auto
Keyboard & Mouse
Front Panel USB Disabled Used to enable the USB ports accessed through
Enabled the internal USB header found on the baseboard.
Memory Configuration Submenu
Feature Choices Description
Extended Memory Test 1 MB Extended memory test options run during POST.
1 KB
Every Location
Disabled Note: the smaller the increment, the longer the test takes
during POST.
Bank #1 N/A Informational screen used to display whether DIMMs are
present in bank #1
Bank #2 N/A Informational screen used to display whether DIMMs are
present in bank #2
Bank #3 N/A Informational screen used to display whether DIMMs are
present in bank #3
Memory Retest Disabled If enabled, BIOS will activate and retest all DIMMs on the
next system boot. This option will be automatically reset
Enabled to disabled on the next system boot.
