MAXDATA PLATINUM Server Board User’s Manual
7
1 Description
Server Board Features
The SCB2 is available in either SCSI or ATA hard drive interface versions as described in Table.
1. The features listed in Table 2 are common to both server board versions.
Table 1. Server Board Versions
Feature Description
SCSI Dual channel Ultra160 LVD SCSI accessible at rear panel I/O and internally
ATA Dual channel ATA 100 RAID
✏ NOTE
The feature set listed in Table 2 only reflects usage with either the 1U Intel
®
SR1200 or the
2U Intel
®
SR2200 server chassis. Third-party or OEM chassis may not provide all of the
features listed below.
Table 2. Server Board Features
Feature Description
Processors Dual processor slots supporting Intel
®
Pentium
®
III processors in a Socket370 Flip
Chip Pin Grid Array (FC-PGA) package.
Memory Six dual inline memory module (DIMM) slots support:
• SDRAM DIMMs: 133 MHz, ECC, registered, PC/133 compliant, 72 Bit,
168-pin, gold contact, 3.3V. A 1U chassis requires low-profile (LP)
1.2-inch DIMMs.
• Up to 6 GB of memory in a 2U chassis.
Graphics Integrated onboard ATI RAGE
®
XL PCI 64 Bit SVGA controller.
Video Memory 8 MB SDRAM of video memory
PCI bus Two PCI riser slots capable of supporting either of the following configurations:
• 1U configuration – one full-length, full-height 64 Bit/66-MHz PCI riser slot
and one Low Profile (LP) 64 Bit/66-MHz PCI riser slot.
• 2U configuration – three full-length, full-height 64 Bit/66-MHz PCI riser
slots and three LP 64 Bit/66-MHz PCI riser slots.
Network Dual on-board 10/100 Network Interface Controllers (NIC)
System I/O
(See Table 1) • One PS/2
®
keyboard/mouse port (6 pin DIN)
• One VGA video port (15 pin)
• Two external USB ports, internal header providing two additional USB
• One external serial port (RJ-45), one internal COM 1 header
• One external SCSI port (SCSI server board only), one internal
• Two NIC ports (RJ-45)
Form Factor Server ATX form factor
