MAXDATA PLATINUM Server Board User’s Manual
45
PCI Configuration Submenu
Feature Choices Description
USB Function Press <Enter> Enters Submenu
Onboard NIC 1 Press <Enter> Enters Submenu
Onboard NIC 2 Press <Enter> Enters Submenu
Onboard SCSI Press <Enter> Enters Submenu (SCSI model only)
Onboard R-IDE Press <Enter> Enters Submenu (ATA model only)
Onboard Video Press <Enter> Enters Submenu
USB Function Submenu
Feature Choices Description
USB Function Enabled Enables the embedded USB controller.
Disabled
Onboard NIC1 and 2 Submenu
Feature Choices Description
Onboard NIC Enabled If enabled, the system uses the embedded NIC.
Disabled
Embedded NIC ROM Enabled Enables the device option ROM.
Disabled
Onboard SCSI Submenu
Feature Choices Description
Onboard SCSI Enabled Enables or disables embedded legacy SCSI controller hardware.
Disabled
Embedded LVD SCSI ROM Enabled Enables the device expansion ROM
Disabled
Onboard R-IDE Submenu
Feature Choices Description
Onboard R-IDE Enabled If disabled, the embedded R-IDE device is turned off
Disabled and the device resources are hidden from the system
Onboard R-IDE ROM Enabled
Disabled If enabled, initializes the embedded R-IDE device expansion ROM
