TABLE OF CONTENTS (Cont.)
Para/Figure/Table Title Page
4. 369A8010 Engine Oil Pressure and Torque Gauge Tubing Pull Test 503............
5. Engine Oil Pressure and Torque Gauge Lines Bleeding and Servicing 504..........
6. Autronics EPO Warning Control Unit Operational Check 504.....................
7. Voice Warning LRU Operational Check (600N) 505...............................
8. Chip Detector Circuit Operational Check 505....................................
9. NR Disable Switch (S199) Adjustment 505.......................................
10. Power Train Instruments Adjustment/Test (600N) 506............................
A. N1 Tachometer 506..........................................................
Table 501. N1 Tachometer Calibration 506....................................
B. NR/N2 (NP) Dual Tachometer Indicator 506...................................
Table 502. Dual Tachometer Calibration 506...................................
C. TOT Indicator 506...........................................................
Table 503. TOT Indicator 506................................................
D. Engine Oil Temperature/Engine Oil Pressure 506..............................
Table 504. Engine Oil Temperature/Engine
Oil Pressure Calibration Data 506..................................
11. Torque Indicator Calibration 507...............................................
Figure 502. Torque Indicator Calibration Instrument 507.......................
12. Digital TOT Indicating System Inspection (369D/E - 500N) 508...................
Table 505. TOT System Test (369D/E - 500N) 508.............................
Figure 503. TOT Wire Harness Termination Verification
(369D/E - 500N) 509.............................................
13. Digital TOT Indicating System Inspection (600N) 509............................
Table 506. TOT System Test (600N) 510.......................................
Figure 504. TOT Wire Harness Termination Verification (600N) 510.............
Initial Installation 901............................................................
1. Analog Digital TOT Indicator Initial Installation 901.............................
A. 369E S/N 384 & Subs - 500N S/N 001 & Subs: 901.............................
B. 369E S/N 001 - 383: 901.....................................................
C. 369D S/N 001 & Subs: 901...................................................
D. Reassembly After Indicator Installation 902...................................
Figure 901. Analog Digital TOT Wiring Installation (Sheet 1 of 3) 903...........
95-50-00 Miscellaneous Instruments A...........................................
Maintenance Practices 201.......................................................
1. Outside Air Temperature Indicator 201..........................................
2. Outside Air Temperature Indicator Replacement 201.............................
3. Running Time Meter 201.......................................................
