Mercury 40 Service Manual

TILLER HANDLE
90-828631R3 MARCH 1999 Page 7B-23
24. Assemble the shift rod into the shift handle.
54286
a
b
a-Shift Rod
b-Shift Handle
25. Secure the shift handle as shown.
c
b
a
95
2-4-C w/Teflon (92-850736A1)
95
a-Shift Handle
b-Bushing
c-Screw
Screw Torque
100 lb-in. (11.3 Nm)

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
