Intake Manifold and Fuel Rail (MPI)
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Balance hose
2 2 Clamp
3 1 Starboard fuel rail
4 1 Valve assembly
5 1 Cap
6 1 Fuel regulator hose
7 1 Port fuel rail
8 3 Clip
9 8 Fuel injector
10 1 J‑clip
11 1 Screw
12 1 Fuel supply module to fuel rail hose
13 1 Grommet
14 1 Clip
15 1 Bracket
16 1 Bracket
17 1 Stainless steel washer
18 2 Worm gear clamp
19 1 Fuel module to water strainer hose
20 3 Screw
21 3 Fuel supply module—dual pump
22 1 Screw 10 88.5 –
23 1 Fuel filter to fuel module line
24 1 Screw
25 1 Clamp
26 1 Hose to fuel tank
27 1 Bracket
28 2 Screw 27 – 19.9
29 1 Filter assembly
30 1 Fuel filter
31 1 Cap
32 1 Screw
33 4 Stainless steel screw 12 106.2 –
34 1 Worm gear clamp
Engine Disassembly
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 3A-17
