Mercury MERCRUISER - Gear Lube Monitor (Sterndrive); Seawater Hoses

Seawater Hoses
Disconnect the seawater hose on all models.
Typical 6.2L seawater pickup
a - Seawater inlet hose
connection
Gear Lube Monitor (Sterndrive)
1. Disconnect the gear lube monitor from the transom.
NOTE: The quick‑disconnect shown below is located at the transom. Some models have a quick‑disconnect fitting in the
gear lube monitor hose closer to the engine. It may be more convenient to disconnect the hose at this alternate location.
Typical Bravo drive connection
a - Hose
b - Quick‑disconnect 90° fitting
c - Seawater inlet fitting
d - J‑clip
2. Place the hose out of the way.
a
58409
a
a
b
c
d
21623
Removal
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 2A-3
