2. Install the return hose onto the power‑assisted steering pump reservoir and secure it with hose clamps.
a - Return hose
3. Install the return hose onto the fluid cooler and secure it with hose clamps.
a - Return hose
4.
Fill and bleed the system. Refer to Filling and Bleeding.
Return Hose (Control Valve to Fluid Cooler)
Removal
NOTICE
Discharge of oil, coolant, or other engine/drive fluids into the environment is restricted by law. Use caution not to spill oil,
coolant, or other fluids into the environment when using or servicing your boat. Be aware of the local restrictions governing
the disposal or recycling of waste, and contain and dispose of fluids as required.
NOTE: Use a suitable container to catch the fluid that drains from the pump and hoses.
1. Note the position and routing of the return hose before removal.
2. Loosen the hose clamp and remove the return hose from the fluid cooler.
a -
Return hose and hose clamp
Power-Assisted Steering Pump and Related Components
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 8A-21
