Mercury MERCRUISER - Engine Block Codes; Identification

To Next Page

To Previous Page

Lubricants, Sealants, Adhesives

Tube Ref No. Description Where Used Part No.

SAE Engine Oil 30W Cylinder bores and other machined surfaces Obtain Locally

Special Tools

Piston Ring Expander 91‑24697

6255

Expands piston rings for removal and installation.

Engine Block Codes

Identification

The engine can be determined by using the block code. This code contains a component code, family code, and year and time

code.

57249

Block code stamped on starter mounting boss
