9. Remove the crankshaft position sensor.

a - Screw

b - Crankshaft position sensor

c - Crankcase front cover

a - Crankcase front cover

b - Cover screws (6)

10. Remove and inspect the crankcase front cover.

IMPORTANT: The crankcase front cover is reusable. Gasket must be replaced if removed.
