1. Apply a 6.35 mm (0.250 in.) wide and 25 mm (1.00 in.) long bead of Loctite 5512 Adhesive to both the right and left side
joints of the rear seal retainer and joints of the front cover.
a - 1/4 in. wide bead Loctite 5512 Adhesive, 1 in. long at front cover
b - Front cover
c - 1/4 in. wide bead Loctite 5512 Adhesive, 1 in. long at rear seal retainer
Tube Ref No. Description Where Used Part No.
137
Loctite 5512 Adhesive
Both right and left side joints of the rear seal retainer and
joints of the front cover
92-858006K02
IMPORTANT: Always install a new oil pan gasket.
NOTE: The oil pan gasket and oil pan must be installed and the fasteners tightened while the adhesive is still wet to the
touch.
2. Install a new oil pan gasket.
3. Install the new oil pan gasket into the groove in the oil pan.
Engine Inspection and Assembly
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 3B-41
