1 - Steering

2 - Digital trim

3 - Pitot

4 - MerCathode

5 - Ground

6 - Trim bypass

7 - Trim from helm

8 - Trim pump

9 - 16‑pin connector

Transom Harness Wiring Diagram (TowSport, Inboard)

a - Transmission shift sensor

b - Steering/pitot sensor

c - 16‑pin transom harness connector

d - Transmission over‑temperature sensor

e - Trim/transmission over‑temperature sensor ground

f - Shift solenoid B

g - Shift solenoid A

h - Reverse pressure sensor

i - Forward pressure sensor

S R P N M L K J H G F E D C B A

GRA

BLK/PNK

YEL/GRN

RED/GRN

PPL/BLK

GRA/RED

WHT/ORN

BLK/GRN

PPL/BLK

GRA/RED

WHT/ORN

WHT/LT BLU

BLK

WHT/BLK

TAN/YEL

BLK

BLK/PNK

GRA

WHT/LT BLU

BLK/PNK

GRA

WHT/BLK

RED/GRN

BLK

YEL/GRN

E D C B A

D C B A

1212

CBACBA

S101

S100

S104

58503
