Exhaust System Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 2 Exhaust tube
2 8 Worm gear clamp, see Note 4–4.7 35.4–41.6 –
3
1 Intermediate elbow kit, non‑riser
1 Intermediate elbow kit, 2‑in. riser
1 Intermediate elbow kit, 4‑in. riser
1 Intermediate elbow kit, 6‑in. riser
4 8 Worm gear clamp, see Note 4–4.7 35.4–41.6 –
5 2 Exhaust tube
6 1 Exhaust pipe
7 2 Water shutter assembly
8 4 Grommet
9 4 Screw 34 – 25.1
10 4 Lockwasher
NOTE: Torque values shown are for Tridon® hose clamps. Refer to
Hose Clamp Identification
.
Exhaust Pipe and Through-the-Propeller Exhaust
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 7C-3
