The image represents the view from the inside of the boat looking at the transom

a - Piston

b - Control valve

c - Power steering fluid cooler

d - Pump

e - Relief valve (inside of the pump housing)

f - Pump housing

g - High pressure

h - Low pressure

Power-Assisted Steering Pump and Related Components
