Tube Ref No. Description Where Used Part No.
28
Dexron® III Automatic Transmission Obtain Locally
IMPORTANT: To accurately check the fluid level, the engine must be operated at 1500 RPM for two minutes immediately
prior to checking the level.
4. Start the engine and operate at 1500 RPM for two minutes to fill all the hydraulic circuits.
5. Stop the engine and immediately check the fluid level with the dipstick resting on the top of the threaded hole.
6. If the fluid level is low, add transmission fluid to bring the level up to the maximum mark on the dipstick.
Tube Ref No. Description Where Used Part No.
28
Dexron® III Automatic Transmission Obtain Locally
7. Install the dipstick.
Filling
1. If necessary, add the specified automatic transmission fluid through the dipstick threaded hole to bring the level up to the
maximum mark on the dipstick.
IMPORTANT: Use only the specified automatic transmission fluid.
a - Dipstick
b - Threaded hole
c - Maximum fluid level
d - Minimum fluid level
Tube Ref No. Description Where Used Part No.
28
Dexron® III Automatic 63A and 63IV transmissions Obtain Locally
2. Install the dipstick.
IMPORTANT: To accurately check the fluid level, the engine must be operated at 1500 RPM for two minutes immediately
prior to checking the level.
3.
Refer to Checking and check the fluid level.
Changing
IMPORTANT: Do not start or crank the engine without fluid in the transmission.
NOTICE
Discharge of oil, coolant, or other engine/drive fluids into the environment is restricted by law. Use caution not to spill oil,
coolant, or other fluids into the environment when using or servicing your boat. Be aware of the local restrictions governing
the disposal or recycling of waste, and contain and dispose of fluids as required.
1. Clean the exterior of the transmission around the fluid filter assembly.
16604
ZF/45C, 45IV, 63A, 65IV Transmissions
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 9A-11
