Tube Ref No. Description Where Used Part No.
9
Loctite 567 PST Pipe
Sealant
Transmission fluid temperature switch threads 92-809822
10. Install and securely tighten the fluid temperature switch.
NOTE: The pressure service port is a metric face‑seal design and requires special adapters.
Model Pressure Service Port Special Adapter
63A and 63IV Parker Hannifin M10‑1/8F8OHG
45C Parker Hannifin M14‑1/8F8OHG
11. Install the pressure service port plug and tighten securely.
12. Connect the two fluid temperature switch wires. Apply Liquid Neoprene to the exposed electrical terminals and
connections.
Tube Ref No.
Description Where Used Part No.
25
Liquid Neoprene Exposed electrical terminals and connections 92- 25711 3
13. Upon first operation, check for leaks.
ZF/45C, 45IV, 63A, 65IV Transmissions
Page 9A-18 © 2016 Mercury Marine 90-8M0099748 eng DECEMBER 2015
