MI 3102(H) BT EurotestXE Instrument operation

4.3 Instruments main menu

In instrument’s main menu the test mode can be selected. Different instrument options can be

set in the SETTINGS menu.

 <INSTALLATION> a.c. LV installation testing

 <AUTO SEQUENCES> custom configured

autosequences

 <OTHERS> other tests / measurements

 <SETTINGS> Instrument settings

Figure 4.3: Main menu

Keys:

UP / DOWN

Selects appropriate option.

TEST

Enters selected option.

4.4 Settings

Different instrument options can be set in the SETTINGS menu.

Options are:

 recalling and clearing stored results,

 selection of language,

 setting the date and time,

 setting earthing system (MI 3102 BT only),

 selection of reference standard for RCD tests,

 entering Isc factor,

 commander support,

 setting the instrument and Bluetooth module to initial

values,

 settings for current clamps,

 settings of length units for specific earth resistance ().

Figure 4.4: Options in

Settings menu

Keys:

UP / DOWN

Selects appropriate option.

TEST

Enters selected option.

ESC / Function

selector

Exits back to main menu.
