METREL EurotestXE User Manual

MI 3102(H) BT EurotestXE Technical specifications
94
10.6 Line impedance and prospective short-circuit current /
Voltage drop
Line impedance
Measuring range according to EN 61557 is 0.25  9.99k.
Measuring range ()
Resolution ()
Accuracy
0.00  9.99
0.01
(5 % of reading + 5 digits)
10.0  99.9
0.1
100  999
1
 10 % of reading
1.00 k  9.99 k
10
Prospective short-circuit current (calculated value)
Measuring range (A)
Resolution (A)
Accuracy
0.00  0.99
0.01
Consider accuracy of line
resistance measurement
1.0  99.9
0.1
100  999
1
1.00 k  99.99 k
10
100 k  199 k
1000
Test current (at 230 V) ........................... 6.5 A (10 ms)
Nominal voltage range ........................... 93 V  134 V (45 Hz  65 Hz)
185 V  266 V (45 Hz  65 Hz)
321 V  485 V (45 Hz  65 Hz)
Voltage drop (calculated value)
Measuring range (%)
Resolution (%)
Accuracy
0.0  99.9
0.1
Consider accuracy of line
impedance measurement(s)*
Z
REF
measuring range ..................................... 0.00 Ω  20.0 Ω
*See chapter 5.7.2 Voltage drop for more information about calculation of voltage drop result
