METREL EurotestXE User Manual

MI 3102(H) BT – EurotestXE Appendix A – Fuse table
104
Appendix A – Fuse table – IPSC
Fuse type NV
Rated
current
(A)
Disconnection time [s]
35m
0.1
0.2
0.4
5
Min. prospective short- circuit current (A)
2
32.5
22.3
18.7
15.9
9.1
4
65.6
46.4
38.8
31.9
18.7
6
102.8
70
56.5
46.4
26.7
10
165.8
115.3
96.5
80.7
46.4
16
206.9
150.8
126.1
107.4
66.3
20
276.8
204.2
170.8
145.5
86.7
25
361.3
257.5
215.4
180.2
109.3
35
618.1
453.2
374
308.7
169.5
50
919.2
640
545
464.2
266.9
63
1217.2
821.7
663.3
545
319.1
80
1567.2
1133.1
964.9
836.5
447.9
100
2075.3
1429
1195.4
1018
585.4
125
2826.3
2006
1708.3
1454.8
765.1
160
3538.2
2485.1
2042.1
1678.1
947.9
200
4555.5
3488.5
2970.8
2529.9
1354.5
250
6032.4
4399.6
3615.3
2918.2
1590.6
315
7766.8
6066.6
4985.1
4096.4
2272.9
400
10577.7
7929.1
6632.9
5450.5
2766.1
500
13619
10933.5
8825.4
7515.7
3952.7
630
19619.3
14037.4
11534.9
9310.9
4985.1
710
19712.3
17766.9
14341.3
11996.9
6423.2
800
25260.3
20059.8
16192.1
13545.1
7252.1
1000
34402.1
23555.5
19356.3
16192.1
9146.2
1250
45555.1
36152.6
29182.1
24411.6
13070.1
