IMD test procedure (MANUAL R, MANUAL I)
 Select the IMD function from the OTHERS menu.
 Select MANUAL R or MANUAL I sub-function.
 Enable and set limit value.
 Connect 3-wire test lead to the instrument and tested item (see Figure 5.58).
 Press the TEST key for measurement.
 Press the UP / DOWN keys to change insulation resistance
*)
until IMD alarms an
insulation failure for L1.
 Press the TEST key to change line terminal selection to L2.
 In case, when IMD switches off voltage supply, instruments automatically changes line
terminal selection to L2 and proceed with the test when instrument detects supply
voltage.
 Press the UP / DOWN keys to change insulation resistance
*)
until IMD alarms an
insulation failure for L2.
 Press the TEST key.
 If IMD switches off voltage supply, instrument automatically proceeds to the PASS/FAIL
indication.
 Use the TAB key to select PASS / FAIL indication.
 Press the TEST key to confirm selection and stop the measurement.
 Store the result (optional).
IMD test procedure (AUTO R, AUTO I)
 Select the IMD function from the OTHERS menu.
 Select AUTO R or AUTO I sub-function.
 Enable and set limit values.
 Connect 3-wire test lead to the instrument and tested item (see Figure 5.58).
 Press the TEST key for measurement.
 Insulation resistance between L1-PE is decreased automatically according to limit value
*)
every time interval selected with timer. To speed up the test press the UP / DOWN keys
until IMD alarms an insulation failure for L1.
 Press the TEST key to change line terminal selection to L2.
 In case, when IMD switches off voltage supply, instruments automatically changes line
terminal selection to L2 and proceeds with the test when instrument detects supply
voltage.
 Insulation resistance between L2-PE is decreased automatically according to limit value
*)
every time interval selected with timer. To speed up the test press the UP / DOWN keys
until IMD alarms an insulation failure for L2.
 Press the TEST key.
 If IMD switches off voltage supply, instrument automatically proceeds to the PASS/FAIL
indication.
 Use the TAB key to select PASS / FAIL indication.
 Press the TEST key to confirm selection and stop the measurement.
 Store the result (optional).
*)
When MANUAL R or AUTO R sub-function is selected, start value of insulation resistance is
determined by
itstart
RR
lim
5.1 
When MANUAL I or AUTO I sub-function is selected, start value of insulation resistance is
determined by
it
LL
start
I
U
R
lim
21
5.1


