MevaLite
ML-25
Stripping Corners - Retract and Reset Tool
Stripping:
Turning the hexagonal nut with
an impact wrench (Fig.25.1), a
ratchet (Fig.25.2) or a wrench
moves the stripping mechanism
upwards.
This activates the stripping corner
and separates the shaft formwork
from the concrete walls (Fig.25.3
and Fig.25.4).
Description Ref.-No.
ML-stripping corners
9’...............................................22-508-00
6’...............................................22-508-10
4’...............................................22-508-20
Stripping corner retract and
reset tool ...................................29-306-32
EA-assembly lock .......................29-205-50
Uni-assembly lock 22 .................29-400-85
Fig. 25.1
Fig. 25.3
Fig. 25.2
Fig. 25.4 Retracted (stripping) position
Wall formwork
Technical Instruction Manual / June 2022
