MFZ Ovitor Control CS 310 - SKS Reversing and Light Barrier Functions

30 – Control CS 310 / Rev.I 1.55
Function Description Setting options Factory settings
SKS REV MOD1: Stop + reverse betwee n OPEN end position and reversing point
Stop between reversing point and CLOSED end position
➜ for vertically closing doors
MOD2 Stop + reverse betwee n OPEN end position and reversing point
No action between reversing point and CLOSED end position
➜ for vertically closing doors with leading photocell
MOD3: Stop + reverse between OPEN end position and CLOSED end
position
➜ for horizontally closing doors and systems with mechanical limit
switches without pre-limit switch
NOTICE:
In systems with mechanical limit switches, the additional CLOSE limit switch serves as
the reversing point.
MOD1 – MOD3 MOD1
REVERS-
POINT. OFF
Reversing point. Point at which the reversing movement of the door is switched off.
Appears only for systems with an electronic end position system (AWG). Setting is
done in increments, starting from the lower travel cut-out point. In systems with
mechanical limit switches, the additional CLOSE limit switch serves as the reversing
point.
A – self teach-in
1 – 1000
50
LIGHT BARR. 1 Photocell 1, installed in the drive-through area of the door. Connection to X4 / 1-4
MOD1: MFZ 2-wire system
MOD2: NC contact / NPN
MOD3: PNP
A – self teach-in
MOD1 – MOD3
A
LB FUNC 1 Function of photocell 1 in the drive-through area of the door.
CLOSING door movement OPENING door movement
MOD1: Stop + reverse No action
MOD2: Stop + short reversal No action
MOD3: STOP No action
MOD4: STOP STOP
MOD5: Stop + reverse Dragging up suppression
(Door OPENING movement not
possible until the photocell is no longer
interrupted).
MOD6: No action Stop + reverse
MOD7: No action Stop + short reversal
MOD8: No action Stop
MOD9: Dragging up suppression Stop + reverse
(Door CLOSING movement not possible until
the photocell is no longer interrupted).
MOD1 – MOD9 MOD1
LB FUNC 2 Function of photocell 2 in the drive-through area of the door.
Only appears if parameter setting INPUT 1 = MOD15.
Connection only possible as an NC contact at programmable Input 1 (X4 / 9+10).
Selection mode similar to the settings under LB FUNC. 1
MOD1 – MOD9 MOD1
PEP POINT Photocell 1 (X4 / 1-4) is not evaluated between the CLOSED end position and the PEB
POINT. Setting is done in increments, starting from the lower travel cut-out point. Only
visible in systems with electronic limit switch.
Please note: When adjusting, this point will be automatically recognised during
therstclosingrun,providedthatPhotocell1isinstalledinthedoorframeandthe
photocell remains interrupted during the closing operation from this point through to
the CLOSED end position.
A – teach-in
1 – UPPER SWITCH
A
Overview of functions
