Control CS 310 / Rev.I 1.55 – 29
Function Description Setting options Factory settings
MOD28: Relay generally OFF
MOD29: Door opens
MOD30: Door closes
MOD31: Service, continuous signal once the pre-set maintenance interval is reached
MOD32: Battery mode
MOD33: Battery operation not possible
MOD34: Firealarmsignal(redetectionandalarmsystem(BMA)active)
MOD35: Photocell operative
MOD36: Wicket door locking cylinder
MOD37: Testing of stop signal through radio transmission systems 1 and 3
MOD38: Testing of light curtain 2 (input 2)
MOD39: LED error
MOD40: Impulse signal when OPEN command is given from outside
MOD41: Test of radio transmission system 4 in OPEN direction
MOD43: Operator in motion
MOD44: (Redtrafclightinside+outside)
DOWN door movement from intermediate position DOWN -
ashing
UP door movement - off
MOD45: Closing edge in function
MOD46: Controller in operating mode ADJUSTMENT
MOD49: Testing presence and movement sensors (NC)
MOD60: (Redtrafclight,outside1)ashesduringforewarningandisONduring
door run
MOD61: (Redtrafclightoutside2)ashesduringforewarningandduringdoorrun
MOD62:
(Greentrafclightoutside)ONatOPENendposition,OFFduringforewar-
ning, and OFF during door run)
*Iftwo-waytrafccontrolisactivated:TrafclightINSIDE
T-LI. REST Switchestrafclights
MOD1: OFF in standby mode
MOD2: ON in standby mode
MOD3: In standby OFF after 5 minutes
MOD1 – MOD3 MOD1
SKS MOD1: OSE (optosensor)
MOD2: 8.2kΩ(electricalcontactstrip)
MOD3: DW Pressure sensor (airwave bar) as NC with testing
MOD4: Light grid OSE or SSR without testing
MOD5: PNP light curtain with testing
MOD6: PNP light curtain without testing
MOD7: 2-wire OSE (photo sensor with 2 connection wires)
NOTICE:
MOD4, MOD5 and MOD6 must be set manually if a light curtain is used.
– Without any addition to the open time (if programmed) after the light curtain has
been interrupted during automatic closing.
– Without switching off “Automatic closing” after 3 interruptions in a row.
A – self teach-in
MOD1 – MOD7
A
DW TEST Activation and deactivation of testing function for the attached DW airwave bar.
Only appears if parameter setting SKS = MOD3.
MOD1: Test OFF
MOD2: Test ON
MOD1 – MOD2 MOD2
DW-POINT Point at which the DW airwave bar attached is tested (X4 / 5+6).
Only appears if parameter setting SKS = MOD3.
Setting is done in increments (only AWG), starting from the lower travel cut-out point.
In systems with mechanical limit switches, the additional CLOSE limit switch serves as
the PS-POINT.
0 – 1000 20
SKS FUNC MOD1: Stop + reverse
MOD2 Stop + 2-second reversing movement
MOD1 – MOD2 MOD1
