44
$
Double-click
or .
$
Press
»
"
« two times and select
»
EQU
«
.
Now you reach the display (default):
➊
Select the required equalizer band via
and change the value via
!
.
(the maximum of +/-64 appropriate +/- 12dB)
%
Leave the function with
.
23. AUDIO functions (Soundcard, Wave & CD)
In the audio menu you can seperately determine the desired audio-output (A, B) and the
output level for:
*
Card
(= a built-in Wavetable or Daughterboard like the MIDITEMP DS-48)
*
Wave
(= the built-in Waveplayer unit)
*
CD (if connected and installed in the Device Drive Manager)
(= an internal/external CD-ROM drive, outputs can only be chosen for
internal drives like in the MP 22-CDW or MP 88-CD ...)
$
select the Audio menu pressing
.
$
for volume settings of the three devices just press the depending number key and change
the value using the
!
.
$
to send the signals to the two Audio outputs (A,B) on the rear of the device just select the
desired Audio outputs by pressing the depending number keys for the different devices.
$
the volume settings for the Audio CD player can be changed in the “
CD Audio
Control
“ menu, too, using the
!
.
%
Leave the mode with
.
&
If you enter the AUDIO menu again you just come to the page you’ve left. E.g. if you left the
function on the “CD Audio Control“ page you will get back there pressing
.
During playback of an audio CD you can turn back to normal mode and select Songs,
Matrix programs etc.
During playback of an audio CD (e.g. if you leave the stage) you can lock the device (see
page 42) to exclude unauthorized usage.
Equalizer of DS-48
Low: +32 midl: 00 midh: 00 high:+32
Audio Out(A
B), Vol.( CD )
))))))))))
))))))))))))))))))))
))))))))))
+
++
+
127
Card A B Wave A B CD A B
#
##
#
