SECTION VI
M11/M11D PARTS LIST
© Midmark Corporation 2000 SF-1803 Printed in U.S.A.
Always Specify Model & Serial Number
3
5
4
7
2
8
6
1
9
6-20
Rev 10/03
Control PC Board
MA594501i
Item Part No. Description Qty Item Part No. Description Qty
1 002-0762-00 M11 PC Board Kit (115 volt)
002-0762-01 M11 PC Board Kit (230 volt)
002-0762-02 M11D PC Board Kit
(Includes Items 2 thru 9)
2 • 053-1259-00 • Insulator ..............................................1
3 • • PC Board.............................................1
4 • 050-5203-10 • PC Board Bracket ............................... 1
5 • 016-0346-07 • Fuse (Fast Acting)............................... 1
6 • 016-0346-10 • Fuse (Slow-Blow)................................ 1
7 • 040-0010-46 • Screw.................................................. 2
8 • 041-0010-04 • Nut ...................................................... 2
9 • 053-1455-00 • PC Board Standoff.............................. 4
