Milestone Srl MA213-003 – DMA-80 EVO – User Manual
85
- Concentrate: a curly brace is shown to indicate the accumulation of samples
measured.
Only a defined maximum volume can be loaded into the sample boat. So, with
the Concentrate function, a large weighing (within the limits) can be distributed
and measured in several sample boats. When a red cross is displayed, it means
that the sample can be removed from the series.
The divided samples are sequentially processed and the accumulated Hg is
burnt and measured only with the last sub-sample. The result is thus determined
over the total originally weighted quantity and the collected Hg value.
Example:
1.Weigh all samples in sequence.
2.Mark the record which contains a sub-sample (sample 1.1).
3.Activate the Button. The sample under the one marked will be connected with
a brace- parenthesis to the marked sample (here sample 1.2).
4.Now select the connected sample (here sample 1.2) and activate the function.
The next sample (here sample 1.3) will also be connected to the first two
samples. Following groups with partial samples can be introduced in the same
way.
The State display also indicates the current status:
Sample has not been weighed yet or the amount has not been
confirmed yet
Sample weighed or amount confirmed
Sample in stand-by (automatic sample mode processing) up for
measurement
Sample was removed during the processing run. Sample is removed
from list once the measurement(s) are completed.
Measurement sample ongoing
Measurement interrupted or invalid
Sample measured succesfully
At the end of measurement, a new option is available if you click on State field:
