OM-253 906 Page 25
5-9. Lifting Eye On Power Source
805 293-A
! Turn Off welding power
source, disconnect input
power.
1 Lifting Eye
The wire feeder allows access to
the lifting eye on the power source.
The entire welding system as
shown with cable hangers, cooler
with coolant, dual feeder, and
running gear can be lifted with the
lifting eye.
The control cable must be
disconnected from the feeder. Use
of a lifting strap may be necessary.
Total weight is approximately 525 lb
(238 kg) excluding welding guns
and cables.
. Be sure that wire spools,
cables and gas bottles are
removed before lifting the
welding system.
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Miller PipeWorx 400 and is the answer not in the manual?

Miller PipeWorx 400 Specifications

General IconGeneral
Amperage Range5 - 400 A
Duty Cycle60% at 400 A
ProcessesMIG, Flux-Cored, Stick, DC TIG, Pulsed MIG
Output Voltage Range10 - 44 V
Wire Feed Speed50 - 780 IPM
