Miller PipeWorx 400 - Wire Feeder Auto Jog Example

OM-253 906 Page 68
6-15. Wire Feeder Auto Jog Example
. Only illuminated controls can be
changed or adjusted.
1 Jog And Trigger Hold Buttons Pressed
Simultaneously
2 Jog Feet Adjustment Knob
3 Jog Feet Remaining Display
4 Jog Wire Feed Speed Adjustment Knob
5 Jog Wire Feed Speed Display
15.3
252 620-C
3
2
4
5
1
780
