Miller PipeWorx 400 User Manual

OM-253 906 Page 56
6-5. Stick Process Selection Setup Example
. Only illuminated controls can be
changed or adjusted.
1 Stick Process Active
2 EXX10 Electrode Type Selected
3 Amperage Setting 350A
4 Memory Location 1 Active
Ref. 252 613-B
1
2
3
4
350

Miller PipeWorx 400 Specifications

General

Amperage Range	5 - 400 A
Duty Cycle	60% at 400 A
Processes	MIG, Flux-Cored, Stick, DC TIG, Pulsed MIG
Output Voltage Range	10 - 44 V
Wire Feed Speed	50 - 780 IPM
