Miller PipeWorx 400 User Manual

OM-253 906 Page 69
6-16. Basic Parameters For PipeWorx 400
Steel
Process
Wire Size
mm
Wire Feed Speed
mpm
Arc Length Shielding Gas
RMD Carbon
0.9 2.5-8.9 w/5.1 Nominal +3.0 to −3.0
w/zero Nominal
C8-C15
0.9 2.5-8.9 w/5.1 Nominal +3.0 to −3.0
w/zero Nominal
C20
0.9 2.5-8.9 w/5.1 Nominal +3.0 to −3.0
w/zero Nominal
C25
0.9 3.8-8.9 w/5.1 Nominal +3.0 to −3.0
w/zero Nominal
100% CO
2
1.0 2.5-6.4 w/4.4 Nominal +3.0 to −3.0
w/zero Nominal
C8-C15
1.0 2.5-7.6 w/4.4 Nominal +3.0 to −3.0
w/zero Nominal
C20
1.0 2.5-7.6 w/4.4 Nominal +3.0 to −3.0
w/zero Nominal
C25
1.0 3.8-6.4 w/4.4 Nominal +3.0 to −3.0
w/zero Nominal
100% CO
2
1.2 1.9-6.4 w/3.8 Nominal +3.0 to −3.0
w/zero Nominal
C8-C15
1.2 1.9-6.4 w/3.8 Nominal +3.0 to −3.0
w/zero Nominal
C20
1.2 1.9-6.4 w/3.8 Nominal +3.0 to −3.0
w/zero Nominal
C25
1.2 2.5-5.1 w/3.8 Nominal +3.0 to −3.0
w/zero Nominal
100% CO
2
RMD Carbon Metalcore
1.2 1.9-5.7 w/3.8 Nominal +3.0 to −3.0
w/zero Nominal
C20
1.2 1.9-5.7 w/3.8 Nominal +3.0 to −3.0
w/zero Nominal
C25

Miller PipeWorx 400 Specifications

General

Amperage Range	5 - 400 A
Duty Cycle	60% at 400 A
Processes	MIG, Flux-Cored, Stick, DC TIG, Pulsed MIG
Output Voltage Range	10 - 44 V
Wire Feed Speed	50 - 780 IPM
