Miller PipeWorx 400 - MIG Process Setup Example 2

OM-253 906 Page 59
6-8. MIG Process Selection Setup Example 2
. Only illuminated controls can be
changed or adjusted.
1 Pro-Pulse MIG Process Active
2 Stainless Steel Wire Type Selected
3 0.9 Wire Diameter Selected
4 98/2 Ox Gas Type Selected
5 Trigger Select On
6 Side Select Left
7 Memory Location 4 Active
1
2
3
252 613-B
7
4
5 6
