Table 31. Parts List—Hold Down Adjustment
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
none
Components
all 2 03 06216A SHIM=HOLDOWN 1/4"THICK
all 3 03 06216B SHIM=HOLDOWN 10GA THICK
all 4 03 06216C SHIM=HOLDOWN 16GA THICK
all 5 W3 06406 *RING=HOLD DOWN CENT-STAMPED
all 6 15G238 HXNUT 5/8-11UNC2B SAE ZINC GR2
all 7 15U315 LOKWASHER MEDIUM 5/8 ZINCPL
all 8 15D125 HXTAPSCR 5/8-11X4-FLTHRD GR5
all 9 15K300 HXCAPSCR 1-8UNC2A X4.5 SAE GR5
Hold Down Adjustment
2 Sheets
6044SR2/SR3, 6044WR2/WR3, 72044SR2/SR3, 72044WR2/WR3
Frame & Suspension
