Milnor 72044SR2 - Cylinder Assembly and Cylinder Door Installation; 6044 Sr2, 7244 Sr2

116
Pellerin Milnor Corporation
Figure 55. Cylinder Assembly and Cylinder Door Installation
Soil Side
Clean Side
Cylinder Assembly and Cylinder Door Installation
5 Sheets
6044SR2, 7244SR2
BPWG6D02 / 2020184
BPWG6D02.1 0000289979 A.4 A.5 4/29/20 4:43 PM Released
Shell, Cylinder & Door
