Table 49. Parts List—Five Compartment Supply
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A AD 36 032A * SUPPLY INJECTOR ASSY 7244SP2, SR2
B AD 36 031A 7244WP2/3 ADD FLUSH SUPPLY IN 7244WP2, WR2
C SA 36 037 *INLET-WATER SUP INJ 72WEV ALL
D A36 04900D ASSY=5FLUSH SUP-7244SG 7244SP2, SR2
E A36 04900B * ASSY,5FLUSH SUPINJ=72DIVCYL 7244WP2, Wr2
F SA 36 017A * PIPING ASSY=7244 SUPINJ ALL
Components
all 1 09R012STDG * 09R012 +MOUNTING HDWRE+INST
all 2 02 15096 BRACKET=DRINTLOKSW-CAD
all 3 03 06263 SUPPLY INJ PIPE MNT
A 4 60E301A19A HOSE= *2.5"ID PE X19"
B 4 60E301A24A HOSE= *2.5"ID PE X 24"
A 5 W2 15831A *TRAP-WELDED=SUPINJ INLET SG
B 5 W3 06292 *ELBOW=SUPPINJ INLET=7244
A 6 60E301A27A HOSE= *2.5"ID PE X27"
B 6 60E301A33A HOSE= *2.5"ID PE X33"
all 7 27A075 T-BOLT HOSECLAMP 2.78-3.09"
all 8 03 06382 COVER=SUPPLY VALVE FRONT SG2
all 9 03 06360 COVER=SUPPLY VALVE TOP
all 10 03 06286A END=SUPPLY VALVE COVER
all 11 03 06286B END=SUPPLY VALVE COVER-FRONT
all 12 03 06253 SUPPORT=SUPPLY INJ PIPING
D 13 03 06323A SUPPLY MNT FRONT=7244SG
E 13 03 06323 MTANGLE, FRONT=FLUSHSUP 72WEU
DI 14 03 06324A SUPPLY MNT REAR=7244 SG
E 14 03 06324 MTG=SUP INJ REAR WES BND@PRT
all 15 03 06373 BAFFLE=SUPPLY TANK
all 16 02 15773 PINCHVALVE TUBE-HYPALON
all 17 27A074 HOSECLAMP 2+1/16-3"CADSC#62040
all 18 W3 06254 *MANIFOLD=72"SUP.INJ.W/OBRACK
all 19 W3 06325 * BUCKET=SUPPLY TANK=72WEDU
all 20 15K096 HEXCAPSCR 3/8-16UNC2X1SS18-8
all 21 24G030N ROLLED WASH.379ID NYLTITE 37W
all 22 15G206 HEXNUT 3/8-16 UNC2 SS 18-8
all 23 15U260 LOCKWASHER MEDIUM 3/8 SS18-8
all 24 15U245 FLTWASH 3/8 STD COMM 18-8 SS
all 25 20C040 SUPERFLEX SILICONE ADH 85GR
all 26 15N174 HXCAPSCR 1/4-20UNC X5/8SS18-8
all 27 24G020N ROLLED WASH.252ID NYLTITE 25W
all 28 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 29 15G170 HEXNUT 1/4-20UNC2 SS18-8
Five Compartment Supply
5 Sheets
72044SP2, 72044SR2, 7244WP2, 7244WR2
Chemical Supply Devices
