Milnor 72044SR2 - Page 160

158
Pellerin Milnor Corporation
Table 50. Parts List—Water Inlets
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A GVW36001 H2O INLTS=MTG HDWE NO SB72SG REFERENCE
B AVW36003 *H2O INLT=COLD ONLY , 72SG
C AVW36004 *H2O INLT=+HOT VALVE, 72SG
D AVW36005 *H2O INLT=+1 FRESH VALVE 72SG
E AVW36002 *H2O INLT=INLT PIPING,72SG
Components
all 1 5SL2ANFA NPT ELBOW 90DEG 2" GALMAL 150#
all 2 5N2ACLSG42 NPT NIP 2XCLS TBE GALSTL SK40
all 3 96D088BCSR 2.00WAT BVAL+ACT/BR/NC/ST/RH
all 4 5N2A18AG42 NPT NIP 2X18 TBE GALSTL SK40
all 5
5SL2ANFB NPTELB 90D SIDEOUT 2"GALML150#
all 6 51P060 PLUG PIPE SQ 2"GALCORED CI 125
all 7
5N2A03AG42 NPT NIPPLE 2X3 TBE GALSTL SK40
all 8 5S2ANFA NPT TEE 2" GALMAL 150#
all 9 5N2A04AG42 NPT NIP 2X4 TBE GALSTL SK40
all 10 5N2A04KG42 NPT NIP 2X4.5 TBE GALSTL SK40
all 11 5SB3A2ADEO NPTHEXBUSH 3X2 GALCI 125#
all 12 5SL3ANFA NPT ELBOW 90DEG 3" GALMAL 150#
all 13 5N3A03AG41 NPT NIP 3X4 TOE GALSTL
all 14 60E303C HOSE 3"ID#7216ETRANS/EQUALIZER
all 15 27A075A T-BOLT HOSECLAMP 3.03-3.34"
all 16 27A032M UBOLT 2"PIPE 3/8-16 ZNC3.5" LG
all 17 15P200 TRDCUT-F HXWASHD 3/8-16X3/4NIK
all 18 15U245 FLTWASH 3/8 STD COMM 18-8 SS
all 19 15U260 LOCKWASHER MEDIUM 3/8 SS18-8
all 20 15G206 HEXNUT 3/8-16 UNC2 SS 18-8
Water Inlets
3 Sheets
72044SR2
Water & Steam
