Table 54. Parts List—Brake Air Cylinder
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A AAC65002 AIRCYL BRAKE SINGLE MOTOR
Components
all 1 02 18650B STEM=2WAY AIRCYL BRAKE 7.88L
all 2 W2 18646 *CYLINDER-AIR=DOUBLEACT BRAKE
all 3 53A031XB BODY-EL90MALE.25X25 #269C-4-4B
all 4 60C132 ORING 2"IDX3/16CS BUNA70 #329
all 5 27B250 SPCRROLL.5ID1.5L.062T STLZNC
all 6 27B34010SS SPACERROLL .51ID.625L.062T SS
all 7 02 02194 PISTON CUP=DUMPVALVE 2+3/8"
all 8 02 18651 WASHER=2 WAY BRAKE CYL
all 9 15G220 NUTLOK THINHX 3/8-24 SS/NYL
all 10 60C106 ORING 5/16ID 1/16CSBUNA70#011
all 11 02 02105B 2.38"ACYL BRASS PISTONCUP WSHR
all 12 02 02085 UP WASHER=2"OD=PISTON CUP
all 13 06 20702E FLOW NOT ACTUATOR CYL HEAD
all 14 02 02101 CYLHEAD W/TAPPED HOLE
all 15 02 17024 SPRING-SS=DUMP 1.5OD4FL40#/"
all 16 W6 20702F *FLOW NOT VLV=AIR-CYL ROD WLD
all 17 60C110 ORING 1/2IDX3/32CS BUNA70 #112
all 18 02 02185 WASHER=PISTON CUP COMP LIMIT
all 19 5N0ECLSBE2 NPT NIP 1/4XCLS TBE BRASS 125#
all 20 51V015 TEE 1/4 FGDBRASS 101T7-444
all 21 53A008B BODYMALECON.25X.25COMP#B68A-4B
all 22 5SCC0EBE NPT COUP 1/4 BRASS 125# W/HEX
all 23 15G185 HXNUT 5/16-18UNC2B SAE ZINC GR
all 24 96M055 DELTROL QUICK EXHAUST VLV.1/4"
all 25 27A005 MUFFLER 3/8" BANTAM B38
