Milnor 72044SR2 - Page 55

Pellerin Milnor Corporation 53
Table 18. Parts List—Drive Chart
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A D36 00360 *DRIVECHART=7244SG2 60CYC
Components
all 1 X3 06039 CLUTCH DRUM+VPUL 72MM
all 2 X2 15106 FLANGE=CLUTCH DRIVE 2.5
all 3 56Q1GSDS 1+3/8" BUSH VPUL QD TYPE SDS
all 4 560685R2SE VPUL 2G3V6.85 (SDS) TYPE QD
all 5 56VR0900M2 VBELT 3V900 EA=1BLT USES 2 BELTS
all 6 56Q1MSK 1+5/8" BUSH VPUL QD TYPE SK
all 7
560685R5SK VPUL 5G3V6.85 (SK) TYPE QD
all 8 56VR067S VBELT 3V670 USES 5 BELTS
all 9 56Q1RSK 1+7/8" BUSH VPUL QD TYPE SK
all 10 561110R4SK VPUL 4G3V11.1(SK) TYPE QD
all 11 56VR112S VBELT 3V1120 USES 4 BELTS
all 12 56Q1GSF 1+3/8" BUSH VPUL QD TYPE SF
all 13 02 19201D V-PUL 8G3V7.95 QD TYPE "SF"
all 14 15K226C SOKCAPSCR 5/8-11X3 BLK
all 15 56Q3DR2S 3+3/16" SPLIT BUSH BROWNING #R2
all 16 54V400 BUSHING=3-15/16=SPECIAL
all 17 15E250 STRSQMACHKEY 1X6 C1018
all 18 03 06330 VPUL BROWN 7C7.0 (R2)35#EA
all 19 X3 06330A VPUL=7GR 7PDX14.5PD=72SG
all 20 56Q2HQ2S 2+7/16"SPLIT BUSH'N BROWN "Q2"
all 21 56070C7Q2 VPUL 7C7.0 Q2=SPCL B#7C70Q
all 22 56VC190XBA SETOF 1-3RCX190+1-4RCX190VBAND SET OF 2 VBAND BELTS
all 23 56Q2TF 2+15/16" BUSH VPUL QD TYPE F
all 24 56130C7FA VPUL 7C13.0(F)TYPE QD=SPECIAL
all 26 56VC120XBA SETOF 1-3RCX120+1-4RCX120VBAND SET OF 2 VBAND BELTS
all 27 56Q1GSK 1+3/8" BUSH VPUL QD TYPE SK
all 28 560470R6SK VPUL 6G3V4.7 (SK) TYPE QD
all 29 56VR053X VBELT 3VX530 USES 6 BELTS
all 30 02 175021 KEY-3/4"SQX6+1/2"LONG-60WE
all 31 54S025A MILNOR, 10,17:1, AIR SEAL 30HP GEAR RED
Drive Chart
3 Sheets
72044SR2, SR3
Drive Assemblies
