Pellerin Milnor Corporation 81
Table 26. Parts List—Autospot Drive Motor
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A G15 13400 MOTOR DRIVE ASSY=AUTOSPOT 7244SR2
B G28 15600 MOTOR DRIVE ASSY=AUTOSPOT 7244WR2
Components
all 1 54N015 SPROCKET BROWN#35A96-6"BORE
all 2 54N008 SPRKT BROWN#35-13X7/8" BORE
all 3 54H164A CLUTCH 12VDC MA-PM02B
all 4 15E006 KEY #6 WOODRUFF 5/32X5/8 SAE10
all 5
15Q068 SOKSETSCR CUP10-24X1/4ZINCALLE
all 7
54G010B43P ROLLCHAIN+CONNLINK 3/8"=AUTO
A 8 02 15865 BASE=AUTOSPOT MOTOR BND@ PRT
B 8 02 175036 BASE=AUTSPTMTR60+72WE BND@PT
all 9 15K105 HXCAPSCR 3/8-16UNC2A1.25 GR5 P
all 10 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 11 02 175027 TAPSTRIP=AUTOSPOT MOTORMOUNT
all 12 15K211 HXCAPSCR 5/8-11UNC2AX1 GR5 ZIN
all 13 15U315 LOKWASHER MEDIUM 5/8 ZINCPL
all 14 15K180 HXCAPSCR 1/2-13UNCAX2 GR5 ZINC
all 15 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 16 15G230 HXNUT 1/2-13UNC2B SAE ZINC GR2
all 17 03 01275 COVER=AUTO CLUTCHWIRES
all 18A 12M036L 1/2" 90-DEG SHORT ELLS
all 18B 12M035 3/8" SCREW-IN CONNECTOR
all 19 15K041 HXCAPSCR 1/4-2OUNC2AX1 GR 5 ZI
A 20 12C0375FN 3/8" FLX NON-METAL CONDUIT
A 21 12M040 3/8" X 90-DEG SEALTITE CONN.
A 23 12H050 HANDYBOX 4X2+1/8X2+1/8
A 24 12H095 HANDY BOX COVER 4+2+1/8
A 25 15P185 TRDCUT-F HXHD 1/4-20UNC2AX3/4
A 29 15U150 LOCKWASHER MEDIUM #10 ZINCPL
A 30 15K018 SKCPSCR 10-24 UNC 3X3/8 BLK
all 31 5SCC0GNF NPT COUP 3/8 GALMAL 150#
all 32 5N0G02AG42 NPT NIP 3/8X2 TBE GALSTL SK40
Autospot Drive Motor
2 Sheets
72044WR2, 72044SR2
Drive Assemblies
