Pellerin Milnor Corporation 83
Table 27. Parts List—4 Inch Idler Shaft Bearing
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A ABI36002 95041# BEARASSY=IDLERSHAFT NOBRAKE
Components
all 1 02 19023 94353A DRIVE BASE ADJ. SCREW 13.5LG
all 2 15G250 HXNUT 1-8UNC2B SAE ZNC GR2
all 3 15U400 LOCKWASHER MEDIUM 1" ZINCPL
all 4 15K225 05Z HEXCAPSCR 5/8-11X2+1/2
all 5
15G238 HXNUT 5/8-11UNC2B SAE ZINC GR2
all 6 15U315 LOKWASHER MEDIUM 5/8 ZINCPL
all 7 15U180 LOCKWASHER MEDIUM 1/4 ZINCPL
all 8 15K030 HEXCAPSCR 1/4-20UNC2X1/2 GR5 ZINC
all 9 15P010 12Z PHILPAN TRDCUTSCRTYP10-24X1/2SS
all 10 15U314 FLATWASHER(USS STD) 5/8" ZNC PLT
all 11 15U450 FLATWASH.1345X3.25X1+11/16 ZINCPLTD
all 12 15G268 HXFINJAMNUT 1+1/2-12UNF2B ZINC GR2
all 13 03 06391A 94266B ROD=1.5UNFX10.5LG=TAKE-UP
all 14 15K235A 03Z HEXCAPSCR 3/4-10X2.5 GR 8
all 15 15U340 LOCKWASH MEDIUM 3/4 ZINCPL
all 16 15U320 FLATWASHER(USS STD) 3/4" UNPLT
all 17 56S22220T 04Z SPHEROLBRG NTN#22220BL1KD/C3
all 18 56AHS20 SNW20 BRG ADAPT 3.5" CYL BORE
all 19 56S22220S 04Z SPHEROLBRG NTN#22220BL1D1C3
all 20 W2 18747E 92257C*TAKE-UP WLMT=4"IDLER SHAFTCS
all 21 03 06444A 79337C CAP=BEARING IDLERSHAFT C.S.
all 22 X3 06154A 92236# IDLER SHAFT 4"DIA 60+72SGU
all 23 X2 18697A 79277C BEARHOUSE IDLER SHAFT FLOAT
all 24 X2 18696A 94283C BEARHOUSE IDLER SHAFT LOCKED
all 25 W3 06388D 91247D *TAKE-UP WLMT SOIL SIDE 4"SHA
all 26 03 06444 79507C CAP=BEARING 4"IDLERSHAFT
all 27 03 06445 94251B WEDGE=SHEAVE+SHAFT=60+72SGU
all 28 53A005B BODYMALCON1/4X1/8COMP #B68A-4A
all 29 53A059A NUT 1/4"BR.HOLYOKE AND #61A-4
all 30 53A501 TUBEINSERT .170"OD
all 31 53A500 1/4" SLEEVE DELRIN
all 32 54M020 GREASEFIT 30DEG 1611-B ALEMITE
all 33 5SB0E0CBEO NPTHEXBUSH 1/4X1/8 BRASS 125#
all 34 53A007B BODYFEMCON.25X.25COMP#B66A-4B
all 35 5N0C01KG42 NPT NIP 1/8X1.5 TBE GALSTL S40
all 36 53A005F BODYFEMCON.25X1/8COMP#B66A-4A
4 Inch Idler Shaft Bearing
2 Sheets
72044SR2
