Pellerin Milnor Corporation 87
Table 28. Parts List—Lower Disc Brake Installation
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A GBR28001 INST=DISC BRAKE=60SG 6044SR2/SR3
B GBR36001 INST=DISC BRAKE=72SG 7244SR2
Components
all 1 ABR28002A ASSY=DISK BRAKE SPLIT BRNG
all 2 ABR28003 DISC ASSY +BALANCE=60+725G
all 3 54KC7961 CALIPER HYD FIXMT 12/20 ROTOR
all 4 03 65203 DISC BRAKE PAD DAMPENER 1/8T
all 5
15C098 HXSOKSTRPBLT 3/4X5+1/2X5/8-11
all 6 01 09294
RETAIN RING-FLANGE(STEEL)+$4S
all 7
56AHS22 SNW22 BRG ADAPTER 4" CYL BORE
all 8 15E260 KEY-DISC BRAKE
all 9 W2 19569 *WELD TORQUE ARM 60+72SG
A 10 02 19570 BRKT=TORQUE ARM MOUNT
B 10 03 06531 BRACKET=TORQUE ARM MT 72SG
all 11 X4 22046C 7/8" DIA. SPACER=COBUCK
all 12 15C095 HXSOKSTRPBLT 3/4X1+3/4X5/8-11
all 13 15G238N HXLOCKNUT NYL 5/8-11UNC STL/
all 14 54AA00PBB BUSH BALL 3/4 RBC-B12L
A 15 02 19573 CHANNEL=TORQUE ARM MT
B 15 03 06530 CHANNEL=TORQUE ARM MT 72SG
all 16 17B132 INDUSTRIAL RETAIN.RING 4000-12
all 17 02 19572A RT BRKT=DISCBRAKE HOLDER FRNT
all 18 02 19572 LT BRKT=DISCBRAKE HOLDER FRNT
all 19 15K054 HXCAPSCR 5/16-18X3/4 GR5 XYLAN
all 20 15U185 FLATWASHER(USS STD) 1/4" ZNC P
all 21 15U210 LOKWASHER MEDIUM 5/16 ZINCPL
all 22 54KC7961B0 O-RING 08-11070 BRAKE 2-660
all 23 54KC7961H2 BRAKEHOSE #W2511 1/8X32" OAL
all 24 52LY0CR001 HEXPIPNIP 1/8"XCLOSE#5404-2-2
all 25 52JY0CR001 ELBOW 1/8"FEM.#5504-02-02
all 26 5N0C03AS82 NPT NIP 1/8X3 TBE 304SS SK80
all 27 52AY0ER003 STR.1/4"MJICX1/8"MP#2404-4-2
all 28 54KMC1125U MASTER CYL TILTON 74–1125U
all 29 W3 65238 *WLMT=MASTER BRAKE CYL BRKT
all 30 AAC65002 2006292 AIRCYL BRAKE SINGLE MOTOR
all 31 02 19576 SPLASH SHIELD=DISC BRAKE
all 32 15K154A HEXCAPSCR 1/2-13X1.5 G8 ZN
all 33 15G230 HXNUT 1/2-13UNC2B SAE ZINC GR2
all 34 15U280 FL+WASHER(USS STD)1/2 ZNC PL+D
all 35 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 36 15K223 HEXCAPSCR 5/8-11X2 GR9 2NC
Lower Disc Brake Installation
5 Sheets
6044SR2, 6044SR3, 7244SR2
Drive Assemblies
