Pellerin Milnor Corporation 15
2. The Terminate button (
) cancels all remaining steps in the formula and starts the shut-
down procedure for the machine. You cannot continue a formula after you use the Terminate
Program button.
3. The Manual mode button (
) has no effect while a formula is running. Push this button
when the display says “Run Formula xx” to start manual mode, where the controls operate as
specified in Section 2.1.2 : Control Functions During Manual Operation, page 16 .
4. The Operator signal light, in the upper left corner of the Signal cancel button (
), is a vis-
ual indicator that operator attention is required. This light is illuminated simultaneously with
the sounding of the operator signal buzzer.
5. Push the Signal cancel button (
) to silence the operator signal buzzer which sounds when
a formula completes normally. Also, if a signal is programmed with a chemical injection in
any formula, push this button to indicate that the chemical has been added and to continue
operation
6. The Next button (
) is not used during normal operation.
7. The display on these machines is a vacuum fluorescent type displaying two lines of twenty
characters each.
8. The Scroll up button (
) functions in much the same manner as the Scroll down button de-
scribed above. Push this button to display the next higher numbered formula in memory. For
troubleshooting, hold the Manual button and press the Scroll up button to view the status of
the first 12 outputs. Hold the Start button and press the Scroll up button to view the status of
the microprocessor inputs.
9. When selecting a specific formula to run, press the Scroll Down button (
) to display the
next lower numbered formula in memory. Push this button with the lowest formula displayed
(Formula 01) to select the highest numbered available formula (maximum of 30 formulas).
For troubleshooting, hold the Manual button and press the Scroll Down button to view the
status of the second 12 outputs.
10. The Door unlock button (
) releases the door lock, allowing the latch on the door to oper-
ate. Hold this button depressed and press firmly on the door latch lever to open the door for
load and unloading.
11. The Run/program keyswitch must be in the Run position (
) unless the machine is being
configured or programmed. All control descriptions listed under Section 2.1.1 : Control Func-
tions During Normal Operation, page 14 are based on the keyswitch being in the Run posi-
tion. Refer to Section 2.1.3 : Control Functions During Programming, page 16 for
descriptions of how the controls operate with the keyswitch in the Program position (
).
12. The Run Indicator light, in the upper left corner of the Start button, is illuminated when a
formula is started by pressing
. If the operator terminates the formula before it runs to
completion (with
), the light goes off when any coast time expires and the door is un-
locked. If the formula runs to completion, the light goes off when the coast time following the
final extract step expires.
