22
Pellerin Milnor Corporation
Display or Action Explanation
03 TMMQ HC L CWSS*
01
This is Page A. In this example, the “03” at the left end of the dis-
play represents the formula number. The “01” below it represents
the step number within that formula. The CWSS* decisions
shown underlined repeat for each chemical programmed in this
step.
03 D E
01
This is Page B. When the cursor is advanced past the last decision
on Page A, Page B appears for the remaining decisions in this
step. The decisions required on both pages vary according to ma-
chine model and options.
2.3.3.3.1 Actions when the Cursor is at the Step Number
BNCXGP02.C05 0000211191 A.4 A.8 1/2/20 1:35 PM Released
Display or Action Explanation
03 TMMQ HC L CWSS*
02 xxxx xx x xxxxx
Typical display with cursor at step number
Indexes forward/backward through the step numbers in this
formula.
Accesses the selected step and positions the cursor at decision T,
or saves all changes and exits this formula if this is the last step of
an existing formula.
Exits this formula, clearing the formula if it has not been saved, or
discarding any changes to a previously existing formula.
2.3.3.3.2 Actions when the Cursor is at a Decision within a Step
BNCXGP02.C06 0000211400 A.4 A.8 1/2/20 1:35 PM Released
Display or Action Explanation
03 TMMQ HC L CWSS*
02 xxxx xx x xxxxx
Typical display with cursor at a decision within a step
Indexes forward/backward through the valid choices for this
decision.
Moves the cursor forward among Pages A and B through each
valid decision in a specific step. This accepts the standard or de-
fault decision if another choice was not previously made.
Moves the cursor backward among the two pages, through each
valid decision within a specific step, except in the following
cases:
If the cursor is at decision T on Page A, it will move to the
step number.
If the cursor is at the first decision on Page B, it will back up
to the first valid decision (C) for the first chemical com-
manded in this bath.
