Milnor E-P Express - T = Type of Step; MMQ = Step Duration; H = Hot Water Valve; C = Cold Water Valve

44
Pellerin Milnor Corporation
Table 7. Sample Formula
Decision
Step
Number
T M M
Q
H
C
L
C W S S
* D E
Chemical
Dose
1 2 0 7 0 1 0 1 1 0 4 0 0 3
2 2 0 2 0 1 1 2 0 3
3 4 0 1 0
2.4.1.1 T = Type of Step
BNCXUP24.C03 0000211000 A.4 A.6 A.3 1/2/20 1:35 PM Released
0 = End Formula always the last step in a formula; signifies that there are no further steps and
prompts the programmer for step decision E = How to End Formula
1 = One-way Wash basket rotates in one direction only throughout this step; used for small
goods
2 = Two-way Wash basket reverses rotation periodically throughout this step; used for goods
which might tangle
3 = Soak Wash basket is stationary throughout this step; drastically reduces mechanical action
4 = Extract basket rotates at maximum speed to eliminate as much water as possible from the
goods
2.4.1.2 MMQ = Step Duration
BNCXUP24.C04 0000210999 A.4 A.6 A.3 1/2/20 1:35 PM Released
Enter the duration of the step in minutes, minutes, and quarter-minutes.
001 step duration of 15 seconds (minumum allowable step duration)
072 step duration of 7:30 (7 minutes and 2 quarter-minutes)
633 step duration of 63:45 (maximum allowable step duration)
NOTE: The total time for a wash formula will be greater than the sum of the individual
step times because of drain times and coast times, which may vary among machine
models.
2.4.1.3 H = Hot Water Valve
BNCXUP24.C05 0000210998 A.4 A.6 A.3 1/2/20 1:35 PM Released
0 hot water valve off for this step
1 hot water valve on for this step
2.4.1.4 C = Cold Water Valve
BNCXUP24.C06 0000210997 A.4 A.6 A.3 1/2/20 1:35 PM Released
0 cold water valve off for this step
1 cold water valve on for this step
2.4.1.5 L = Bath Level
BNCXUP24.C07 0000210996 A.4 A.6 A.3 1/2/20 1:35 PM Released
1 low bath level
2 high bath level
Programming
