of the bottom line indicates the number of seconds remaining in
the longest programmed injection.
23:04 STEP# 01 02:37
CHEM 1+2 025
23:04 F02S01 02:37
23:04 is the time remaining in the formula.
F02S01 indicates that the current formula is 02 (F02) and the cur-
rent step is 01 (S01).
02:37 is the time remaining in this step.
23:04 EXTRACT 02:37
EXTRACT indicates that the machine is currently executing an
extract.
TIMEHALT indicates that the timer is stopped while a chemical is
being injected. The chemical supplier must connect equipment for
this option.
L=A0/D2 Hot Rinse
L=A0/D2 indicates that level 1 (low level) has not been achieved,
and level 2 is desired. A1/D2 indicates that level 1 is achieved,
but level 2 (high level) is desired.
The programmed step type appears to the right of the level indica-
tor. The step type includes the temperature range, indicating which
water valves are used to fill the machine.
3.1.5 How to Shorten, Terminate, or Suspend a Running
Formula
BNCJHO03.C08 0000208864 A.4 A.3 1/2/20 1:16 PM Released
Display or Action Explanation
Cancels a step. Advances the step timer to zero for any bath, a
drain not followed by an extract, or any extract in progress. The
next step begins automatically.
This operation is possible only if DIP switch 6 on the processor
board is in the off position, allowing the cancelling of steps.
Cancels the current formula and returns the machine to the Run
Formula display.
RUN FORMULA
00 OK TO POWER OFF
This is the Run Formula display. The door interlock delay, de-
scribed in Section 3.1.3 : Unloading the Machine, page 53 , must
expire before the door can be opened.
3.1.6 How to Restart after Power Loss
BNCJHO03.C09 0000209064 A.4 A.3 1/2/20 1:16 PM Released
The E-P Express
®
control remembers the formula and step it was executing if power fails or if
the wall disconnect is turned off while the machine is operating in automatic mode.
Display or Action Explanation
PRESS START TO RUN
STEP xx - FORMULA yy
On most machine models, this display appears when power is re-
stored. The formula and step which were in progress when power
was interrupted are shown.
