Pellerin Milnor Corporation 77
5.4.2 Configuring the Citizen GSX-190 Printer
BNCUUI01.R02 0000196630 A.4 A.6 A.7 1/2/20 1:30 PM Released
Table 25: Required Settings for Citizen GSX-190 Printer, page 77 lists the required settings for
this printer model to work properly with Milnor equipment. To print the current settings stored in
your printer, move the Menu slide switch on the printer to the VuePrint position, then hold the
Print button for three seconds. Hold the Menu button for three seconds to enter the VuePrint
menu system to make changes.
Table 25. Required Settings for Citizen GSX-190 Printer
Menu
Data Field
Value Menu
Data Field
Value
Install 1
Ribbon Normal
Character
Slash zero Off
A.S.F.
Off Character set Graphics
Emulation
Epson
Intl character set
U.S.A.
Print Style
Font
Draft Code page
U.S.A.
Emphasized Off
Install 2
Tear off Off
Pitch 10 characters inch
Paper out
Enable
Front lock Off Auto linefeed Off
Page Layout
Line spacing 6 lines per inch Copy mode Off
Form length
Letter
Envelope Off
Page skip Off
Serial I/F
Baud rate
9600
Print Mode
NLQ Dir Uni-directional Parity
Even
Graphic Dir Uni-directional Data bits 8 bits
Stop bits 1 bit
Protocol
DTR
5.4.3 Configuring the Epson LX300 Printer
BNCUUI01.R03 0000196629 A.4 A.6 1/2/20 1:30 PM Released
The Epson model LX300 printer was supplied by Milnor prior to March 2001 to print data from
microprocessor controllers with printing functions. When shipped from Milnor, this printer was
configured to operate correctly with Milnor equipment. If the printer is replaced or must be recon-
figured for any reason, refer to the user's guide and the following table.
Table 26. Required Settings for Epson LX300 Printer
Data Field
Value
Data Field
Value
Character spacing 10 characters per inch
Tractor
Single
Shape of zero
0
Interface Serial
Skip over perforation Off Bit rate 9600 bps
Character table
PC 437
Parity
Even
Auto line feed Off Data length 8 bits
Page length 11 inches ETX/ACT
On
Auto tear off Off
