Milnor E-P Express Reference Manual

Pellerin Milnor Corporation 63
COLD WATER VALVE
0=OFF 1=ON 0
Example display with output accessed and disabled.
Enables the output (turns the output on).
COLD WATER VALVE
0=OFF 1=ON 1
Example display with output enabled. The cold water valve is
open.
If the output was already on, this keystroke turns it off.
COLD WATER VALVE
0=OFF 1=ON 0
Example display with output disabled. The cold water valve is
closed.
Disables (turns off) the output if it was previously enabled, and
advances to the next output.
HOT WATER VALVE
0=OFF 1=ON 0
Display after pressing to advance to the next output.
Disables the output if it was enabled, then returns to the Run
mode.
RUN FORMULA
00 OK TO POWER OFF
Display of Run mode.
Table 20. E-P Express
®
Outputs
Output
Number
Page-
Column
Description
Device
MTA
Consequences of Actuation
1 0–a
Inject chemical 5
K1 5–2/5–11
Operates inject device for chemical 5
2 0–b
Inject chemical 1
K2 5–3/5–1
Operates inject device for chemical 1
3 0–c
Inject chemical 4
K3 5–4/5–1
Operates inject device for chemical 4
4 0–d
Inject chemical 3
K4 5–5/5–1
Operates inject device for chemical 3
5 0–e
Inject chemical 2
K5
5–6/5–1
Operates inject device for chemical 2
6 0–f Hot water valve K6 3–2/3–1
Opens valve
7
0–g
Cold water valve
K7
3–3/3–1
Opens valve
8
0–h Drain solenoid
K8
3–4/3–1 Closes drain
9
0–i Flush valve
K9
3–5/3–1
Opens flush valve
10
0–j
not used K10 3–6/3–1
11 0–k not used K11 3–7/3–1
12 1–a not used K12 3–8/3–1
13 1–b not used K13 3–9/3–1
14
1–c
not used K14 3–10/3–1
15
1–d not used
K15
3–11/3–1
16 1–e
not used (Door open de-
sired on MWR_ models
with WUMWRXGG
software)
K16 3–13/3–14
16 1–e Door lock K16 3–13/3–14
17
1–f Unlock door
K17
3–15/3–16
Energizes door latch to unlocked
position
18
1–g
not used
K18
3–18/3–17
19
1–h
Extract speed (use only
with empty cylinder)
K19
3–19/3–17
Locks door and turns cylinder at extract
speed
