4-27
4
Maintenance
Washing the Head
When you move the machine or you do not use the machine for a long time (for one month and more), wash the
head and the ink discharge passage by the procedures below:
1
Press the key in the local mode.
2
Select the [MAINTENANCE] by pressing the or
key, and press the key.
3
Select the [HEAD WASH] by pressing the or
key, and press the key.
4
Press the , , or key to select the
head to wash.
(1) Select the head with or keys.
(2) Select execution/non-execution of the head cleaning with or keys.
• Select execution of cleaning for every head.
• Wash ：:Head No. being set is displayed.
• Do not wash ：ì _ î is displayed.
• When you wash all heads, display all head numbers.
• When you wash the head one by one, display one head number (two).
5
Press the key.
6
Remove the ink cartridge.
• Remove all ink cartridges corresponding to the head selected in the Step 4.
• When the ink cartridge is removed, ink discharge starts.
• When ink discharge has been completed, the right screen is
displayed.
• This machine is equipped with three heads.
• To wash one head, two washing liquid cartridges (SPC-0516FS) are required at the minimum. Before
performing the work, prepare new washing liquid cartridge.
• When you wash all heads at the same time, prepare six washing liquid cartridges with third part of them
remains.
• To restart drawing after washing the head, ink filling is required. ( P.4-29)
To Next Page
