Test drawing

2-7

2

Basic Operations

Normal pattern

Abnormal patterns

Nozzle drop out Nozzle missing Deflection

Many lines are missing.

The lines are missing as if the

teeth are lost.

The distance between the

lines is narrowing or double

lines are formed.
