Disassemble the Assemblies Repair and Disassembly
6 - 32 046-001141-00 A5/A3™ Service Manual
FIGURE 6-57
6.2.4.3 Remove the Touch Screen Control Board
1. Remove display assembly.
2. Remove the four screws and the cover plate of the touch screen control board.
FIGURE 6-58
3. Unplug the related cables from the touch screen control board.
